CL-38uC | Preamplifier

• Made in Japan

The CL-38uC and MQ-88uC combine LUXMAN's history of producing fine vacuum tube products and the traditional wisdom and skills gained along the way.

Click here for more information

• Input sensitivity/input impedance: PHONO (MM): 2.0mV/47kΩ | PHONO (MC high): 0.3mV/100Ω | PHONO (MC low): 0.08mV/30Ω | LINE: 190mV/50kΩ | BAL.LINE: 190mV/20kΩ *2
• Output/output impedance: Rated 1V/300Ω
• Frequency response: PHONO: 20Hz to 20kHz (±0.5dB) | LINE/BAL.LINE: 10Hz to 70kHz (within -3.0dB)
• Total harmonic distortion: 0.006% or less (1kHz) | 0.06% or less (20Hz to 20kHz)
• S/N ratio (IHF-A): PHONO (MM): 68dB or more | PHONO (MC high): 63dB or more | PHONO (MC low): 60dB or more | LINE/BAL.LINE: 100dB or more
• Tone control: ±8dB, selectable frequency range | BASS: 150/300/600Hz, | TREBLE: 1.5k/3k/6kHz
  Low cut: 30Hz(-6dB/oct.)
• Circuit: SRPP
• Vacuum tubes: ECC83S×3, ECC82×5
• Power supply: 230V~(50Hz)/115V~(60Hz)
• Power consumption: 35W
• External dimensions: 440(W) x 169(H) x 307(D) mm
• Net weight: 13.3kg (main unit)

3 years
