M-10X | Stereo Amplifier

• Coup de Coeur
• Made in Japan
• Pure class A operation up to 12W

• Stereophile

The M-10X marks the start of a new era for LUXMAN.

Click here for more information

• Rated output: 150W + 150W (8Ω)/at stereo | 300W + 300W (4Ω)/at stereo | 600W (8Ω)/at monaural
• Instantaneous max. output: 1,200W + 1,200W (1Ω)/at stereo | 2,400W (2Ω)/at monaural
• Input sensitivity: 1.24V/150W (8Ω) | GAIN 29.0dB
• Input impedance: Unbalanced 51kΩ | Balanced 28kΩ
• Frequency response: 20Hz to 20kHz (+0, -0.1dB) | 1Hz to 130kHz (+0, -3.0dB)
• Total harmonic distortion: 0.003% or less (1kHz/8Ω) | 0.04% or less (20Hz to 20kHz/8Ω)
• S/N ratio (IHF-A): 117dB
• Amplification feedback circuit: LIFES 1.0
• Output configuration: 3 stage Darlington 4 paralleled push-pull
• Damping factor: 600
• Power consumption: 540W | 290W (under no signal) | 1.0W (at standby)
• External dimensions: 440(W) x 224(H) x 488(D) mm
• Net weight: 48.4kg

3 years
